Electrical Specification

Input Voltage Range

100Vac-240Vac

Efficiency

≥77.76%

Output Voltage

DC12V

Rated Output Current

1A

Output Power

12W

No Load Power Consumption

≤0.3W

Protection/Environmental

Surge Protected

Line to ground: ±4KV

Line to line: ±2KV

ESD

Contact discharge: ±4KV

Air discharge: ±8KV

Protective Function

Over voltage protection, over current protection, short circuit protection, input protection

Working Temperature

0°C ~ +40°C(32 °F ~ +104 °F)

Working Humidity

10%~90%(RH)

Storage Temperature

- 40°C ~ + 80°C( - 40 °F ~ + 176 °F)

Storage Humidity

5%~95%(RH)

Physical Properties

Installation

Wall-mount

Net Weight

0.074kg(0.16lb)

Gross Weight

0.089kg(0.19lb)

Dimension

60.6 mm × 29.0 mm × 40.0 mm (2.39"

×1.14" ×1.57") (L × W × H)

Package Dimension

85.0 mm × 83.0 mm × 32.0 mm (3.35"

×3.27" ×1.26") (L × W × H)

Color

Black

Input Plug

2-pin North American plug

Output Cable Length

1500 mm

Output Plug

Φ5.5 mm × Φ2.1 mm × 10 mm (Φ0.22" ×

Φ0.08" × 0.39")

Safety Standards

Certification

FCC
